VaporCommander™
Cost-Effective, low maintenance, multiphase vapor recovery technology
Low-Cost, Multiphase, Fully Autonomous Vapor Recovery Technology
We offer the most advanced vapor recovery technology at a more economical price than conventional technologies.
Built with sturdy high-quality components and advanced proprietary programming to optimize operation and functionality.
Designed to maximize project economics
Return on Investment
Total Cost of Ownership
Initial Purchase Cost
Operating Costs
Unmatched benefits and value
Low Cost and Quicker Payout
VaporCommander™ low cost provides a maximum rate of return and reduces the total ownership cost. Similar price as combustors in low-flow applications, with the additional ability of keeping gas instead of burning it.
Broad Operating Range
100% turndown offers a significantly greater flow operating range without the need for any mechanical recirculation configurations. VaporCommander™ handles a large range of line pressure.
Multiphase Operation
Patented multiphase operation can handle up to 100% liquids or any combination of liquids and gas without a scrubber. Gas volume fractions (GVF) between 0 and 100%.
Fully Autonomous with Comprehensive Controls
Works autonomously to achieve operator-defined operational targets. Features comprehensive controls to configure for any complex or upset condition. Very well suited for vapor recovery applications with varying flow, line pressure, and liquid content.
Low Maintenance
The simple and robust design and comprehensive controls ensure significantly reduced maintenance cycles.
Portability
Does not require rigid support for operation. Trailer-mounted units are available.
Select Your VaporCommander™ Model
Scroll horizontally on smaller screens to view the full table.
| VaporCommander™ Model | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| VCx1020 | VCx10353 | VCx25353 | VCx50353 | VC12453 | VC1645 | VC2245 | VC2270 | ||
|
Max Gas Rate1,2 @ Inlet Pressure (e3m3/day) [mcf/day] |
0 psi [ 0 kPa] | 1.5 [53] | 2.4 [85] | 2.4 [85] | 2.4 [81] | 2.4 [81] | 4.2 [145] | 8.0 [279] | 8.0 [279] |
| Max Pressure Differential2 (kPag) [psig] | 1138 [165] | 1138 [165] | 1138 [165] | 1379 [200] | 2413 [350] | 1379 [200] | 689 [100] | 1896 [275] | |
| Motor Size (HP) | 10 | 10 | 25 | 50 | 50 | 100 | 100 | 150 | |
| H2S Handling | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |
| 3-Stage Cold Weather Startup | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |
| Autonomous Controller | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |
| Color Touchscreen & Remote Control | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |
1 Flow conditions calculated at 15°C [59°F] inlet pressure and with various components operating at 100% efficiency. Flow rates may vary based on inlet pressures, gas content, and other factors. Max gas rates will be reduced by amount of liquids in total fluid. Ask Fluidstream for max gas flow rates based on specific liquid rates and other varying conditions.
2 Max gas rates and max pressure differentials can be increased by configuring additional unit(s) in parallel or in series.
3 Higher horsepower units will yield much higher fluid flow rates at various pressure differentials. Please request pump curves to see flow rates at various pressure differentials.
Let’s discuss your vapor recovery requirements
Connect with us to explore how VaporCommander™ can support low-cost recovery, autonomous operation, and better overall project economics.
